We offer a wide range of high quality of equipment & machines for food drying.
+86 18595613260
The garlic powder machine use the high-speed relative movement between the movable sprocket and the fixed sprocket to make the dried garlic slices get crushed garlic powder through the comprehensive effects of the sprocket impact, friction and the impact of the dried garlic slices on each other. Adjustable from 20-120 mesh.
The feeding valve can control the feeding size at any time;
Cooling fan, high-power cooling fan to ensure long-term operation of the machine;
The inner wall of the casing is completely machined to achieve a smooth surface, which has changed the phenomenon of rough inner wall and powder accumulation of previous models.
Model | GGS180B/C | GGS20B/C | GGS30B/C | GGS40B/C | GGS50B/C | GGS60B/C |
Capacity(KG) | 5-20 | 50-100 | 50-200 | 100-400 | 200-500 | 200-800 |
Discharge fineness | 20-120 | 20-120 | 20-120 | 20-120 | 20-120 | 20-120 |
Cutter diameter(mm) | 150 | 200 | 300 | 350 | 500 | 550 |
monitor rate(KW) | 1.5 | 4.0 | 5.5 | 11.0 | 15.0 | 18.5 |
Dust removal power(KW) | 0.55 | 0.75 | 1.1 | 1.5 | 2.2 | |
Total Weight(KG) | 60 | 140 | 220 | 440 | 560 | 620 |
Dust removal weight(KG) | 110 | 230 | 310 | 560 | 680 | 760 |
Dimensions(mm) | 450*350*950 | 600*500*1170 | 750*600*1370 | 800*700*1450 | 850*950*1550 | 900*1100*1750 |
Dust removal size(mm) | 800*500*1200 | 1000*500*1400 | 1200*700*1850 | 1350*900*2000 | 1400*900*2150 | 1600*1100*2300 |
The high-speed crushing cavity, high-hardness solid teeth and high-speed rotating teeth allow the passing material to be crushed as much as possible. After crushing, the appropriate fineness is screened by the screen and flows out of the discharge port.
The hopper is enlarged, and the rounded edge is designed to prevent cutting hands. The cutting is more assured and easier. Rotating screws on the outside can control the speed of the cutting.
The wide round discharge port, the stainless steel sleek discharge port does not stick to the material, the discharge is faster, smoother, and more convenient to clean, and there is no need to worry about the problem of mixing.
Pure copper motor, the rotating shaft of the brand pure copper core motor is directly drawn from the motor, which is stable and efficient, strong power, low noise and durable.
